100% Recycled Material PP Packing Strap Making Machine Thickness
0.4-1.2mm
100% Recycled Material PP Strap Extrusion 1 To 3 Machine Thickness
0.4-1.2mm
Description of PP strap band production machine:
This production line is used for making full automatic PP strapping
band and manual PP strap band for packing use. The width of the strap band is 5-19 mm, thickness is from 0.4-1.2
mm.
Packing belt equipment adopts 38CrMoALA extruderespecially suitable
for high-grade packing belt production, extruder hopper type
dehumidifying drying system and automatic feeding system, make the
performance of the extruder is more stable, the unit all adopts
frequency conversion motor drive and automatic intelligent
temperature control system, realize the energy saving effect
greatly.
Parameters of PP Belt Strapping Band Production Line:
1 | Materials | Polypropylene PP raw material pellets, recycled pellets. |
2 | Product | PP strap (1 mould for 3 straps) |
3 | Capacity | 150-200kg/h |
4 | Total install power | 100kw, (actual power consumption is 50-60%) |
5 | Strap width | 5mm-19 mm |
6 | Thickness | 0.4 mm-1.2 mm |
7 | Manpower | 2person/shift |
8 | Workshop required | L (36m) ×W (2m) ×H (4m) |
9 | Cooling water | ≤20℃,≥0.3Mpa, 5-8Ton/hr |
10 | Compressed air | 0.5-0.8Mpa |
11 | Power source | 380V, 50Hz, 3Phase (according to customer requirement) |
12 | Electric components | Schneider |
13 | Inverter | INVT |
14 | Switches | Fotek |
15 | Motor power | Siemens |
16 | Machine frame | 100*100*2.5 mm(GB quadrate pipe) |
Process flow of PP packing belt production line:
① Feeding →② stirring →③ pre-drying →④ melting and measuring
extrusion →⑤ embryo (belt embryo) cooling and forming →⑥ oven
preheating →⑦ primary stretching →⑧ secondary stretching →⑨
embossening →⑩ oven tempering and setting →⑪ cooling →⑫ finished
product winding
Remarks: If there is a printing machine after the second stretching
first printed and then embossed in item 8.
Application of PP strapping:
PP strapping is mainly used to bind lighter objects. The cartons
what we usually use are sealed with PP packing belts, and the
tension can reach between 50kgs-240kgs depending on different
widths and thicknesses.
Advantages for PP Making Machine:
The production of plastic materials can be made of recycled
materials or mixed new materials to produce packing belts.
The cutting of foreign-quality CNC machine tools and high-precision
die parts make the product forming quality stable and the thickness
error range is less than the national acceptance standard for
packing straps.
The unique cooling cycle system and multiple sets of shaped guide
rails make the packing belt cooler and shrink better and more
accurate in size. The internal reciprocating winding method makes
full use of heat energy and effciently reduces power loss.
The equipment adopts intelligent PLC Chinese/English control
system, simple to understand, beautiful, durable, long life, low
failure rate. The equipment has an exclusive parameter memory
system, the data of each specification after production can be
stored,the next production can directly call out the parameters.
FAQ:
Q1: Are you a trading company or a manufactory?
A1: We are a manufactory,can give u best service.
Q2: What's your guarantee or the warranty of the quality if we buy
your machines?
A2: We offer you high quality machines with 1 years guarantee . we
will give u spare part free in 1 years.
Q3: When can I get my machine after I paid?
A3: We will deliver the machines on time as the date we agreed both
side.
Q4: How can I install my machine when it arrives?
A4: We will send our engineer to your side as soon as you get all
your machines ready , for testing and teaching your technicians how
to run the machines.
Q5: How about the spare parts?
A5: After we deal down all the things , we will offer you a spare
parts list for your reference.
